Hello World in Strawberry Fields

Strawberry Fields is Xanadu’s Python library designed for photonic quantum computing. This approach represents a fundamentally different method compared to qubit-based systems such as Qiskit or Cirq. Rather than using qubits, which represent discrete 0/1 states, photonic computing utilizes optical modes-quantum states of light described by continuous variables. The central quantities here are the quadratures of the electromagnetic field: position (X) and momentum (P), which are analogous to the real and imaginary parts of a quantum harmonic oscillator. This continuous-variable approach offers several practical advantages. For instance, the photonic circuits themselves operate at room temperature, although the photon-number detectors used in current systems still typically require cryogenic cooling. They are also naturally suited for Gaussian Boson Sampling, a problem believed to demonstrate quantum advantage. Xanadu’s Borealis photonic processor demonstrated quantum advantage in 2022. Because of its nature, continuous-variable systems perform exceptionally well in fields like optimization, molecular simulation, and quantum machine learning.

Installation

pip install strawberryfields

For the TensorFlow backend (needed for quantum machine learning):

pip install strawberryfields[tf]

Understanding the Basics

Strawberry Fields programs operate using quantum optical modes, not qubits. You can configure the system to handle two, four, or eight modes.

The available gates correspond to specific optical operations. The Sgate(r) operation squeezes the state, reducing uncertainty in one quadrature, which is analogous to a rotation on the Bloch sphere in qubit systems. The Dgate(α) shifts the state in phase space, similar to a shift operation. For two modes, the BSgate(θ, φ) acts as a beamsplitter, mixing the two modes and serving as an analogy for a two-qubit gate. Two-mode squeezing, implemented by S2gate(r), creates entanglement and is somewhat comparable to a CNOT gate. Finally, Rgate(φ) performs a phase rotation, equivalent to a Z rotation.

When running simulations, you select a backend based on what the system needs to model. The "gaussian" backend is efficient for simulating only Gaussian states, relying on classical simulation methods. If you require full Fock (photon-number) states, the "fock" backend provides an exact, though computationally expensive, simulation. For machine learning applications, the "tf" backend is available, as it is differentiable using TensorFlow.

Single-Mode Squeezed State

The simplest non-trivial program involves squeezing the vacuum state and then displacing it.

import strawberryfields as sf
from strawberryfields.ops import Sgate, Dgate, MeasureX

# Create a program with 1 optical mode
prog = sf.Program(1)

with prog.context as q:
    Sgate(0.5) | q[0]     # Squeeze vacuum by r=0.5 (reduces position uncertainty)
    Dgate(1.0, 0) | q[0]  # Displace by α=1.0 (real part)
    MeasureX | q[0]        # Measure the X (position) quadrature

# Run on the Gaussian backend
eng = sf.Engine("gaussian")
result = eng.run(prog, shots=5)

print(result.samples)
# e.g. [[1.23], [0.91], [1.45], [0.78], [1.12]]
# Continuous values near 1.0 (our displacement), with reduced spread (squeezing)

The vacuum state, $|0\rangle$, serves as the starting point for every mode: zero photons, minimum uncertainty. Applying $Sgate(0.5)$ performs a squeeze, which reduces position uncertainty by $e^{-0.5}$ while increasing momentum uncertainty. Next, $Dgate(1.0, 0)$ shifts the entire state to a position near $1.0$ in phase space. Finally, $MeasureX$ samples the position quadrature, yielding a continuous value rather than a simple $0$ or $1$.

This approach allows us to create a Bell state analog. By using two-mode squeezing, we generate continuous-variable entanglement, which is known as an EPR state.

import strawberryfields as sf
from strawberryfields.ops import S2gate, MeasureX, MeasureP

prog = sf.Program(2)

with prog.context as q:
    S2gate(1.0) | (q[0], q[1])  # Two-mode squeezing: entangle modes 0 and 1
    MeasureX | q[0]               # Measure position of mode 0
    MeasureP | q[1]               # Measure momentum of mode 1

eng = sf.Engine("gaussian")
result = eng.run(prog, shots=10)

print(result.samples)
# Each row: [x_mode0, p_mode1]
# x_mode0 and x_mode1 will be correlated (EPR state property)

The two-mode squeezed state serves as the continuous-variable equivalent of an entangled Bell state. When the squeezing parameter approaches infinity (r → ∞), measuring one mode’s position yields precise knowledge of the other mode’s position, and measuring momentum gives anti-correlated results. This behavior is the continuous-variable analog of quantum entanglement.

The beamsplitter functions as a two-mode gate. It mixes two modes, much like a half-silvered mirror in optics. This gate is a primary component in photonic computing.

import strawberryfields as sf
from strawberryfields.ops import Sgate, BSgate, MeasureFock
import numpy as np

# Hong-Ou-Mandel effect: two photons → bunch together
prog = sf.Program(2)

with prog.context as q:
    # Put one photon in each mode (displaced squeezed states approximate this)
    Sgate(2) | q[0]
    Sgate(2) | q[1]

    # 50/50 beamsplitter (θ = π/4)
    BSgate(np.pi / 4, 0) | (q[0], q[1])

    # Measure photon number in each mode
    MeasureFock() | q

eng = sf.Engine("fock", backend_options={"cutoff_dim": 6})
result = eng.run(prog, shots=10)

print(result.samples)
# With two photons hitting a 50/50 beamsplitter:
# Hong-Ou-Mandel effect: both photons tend to exit the same port
# You'll see (0,2) and (2,0) much more than (1,1)

Gaussian Boson Sampling (GBS) is a protocol proposed by academic researchers in 2017 and developed extensively by Xanadu. It addresses a problem believed to be classically hard, but which photonic quantum computers can solve efficiently. The process samples from the output distribution of squeezed light passing through a random interferometer.

import strawberryfields as sf
from strawberryfields.ops import Sgate, BSgate, MeasureFock
import numpy as np

# Small 4-mode GBS circuit
prog = sf.Program(4)

with prog.context as q:
    # Squeeze each mode
    Sgate(1.0) | q[0]
    Sgate(1.0) | q[1]
    Sgate(1.0) | q[2]
    Sgate(1.0) | q[3]

    # Random interferometer (beamsplitters + phases)
    BSgate(np.pi/4, 0) | (q[0], q[1])
    BSgate(np.pi/4, 0) | (q[2], q[3])
    BSgate(np.pi/3, np.pi/6) | (q[1], q[2])
    BSgate(np.pi/4, 0) | (q[0], q[1])
    BSgate(np.pi/4, 0) | (q[2], q[3])

    MeasureFock() | q

eng = sf.Engine("fock", backend_options={"cutoff_dim": 5})
result = eng.run(prog, shots=20)

print(result.samples)
# Rows like: [0, 1, 2, 0], [1, 0, 0, 2], [0, 2, 0, 1]
# Each value is the photon count in that mode

The sampling distribution relates to hafnians of submatrices: these are #P-hard to compute classically, yet easy to sample from using photonic hardware.

When using the Gaussian backend, a key advantage is that you can query properties of the state without collapsing it.

import strawberryfields as sf
from strawberryfields.ops import Sgate, Dgate
import numpy as np

prog = sf.Program(1)
with prog.context as q:
    Sgate(0.5) | q[0]
    Dgate(1.0, 0.5) | q[0]

eng = sf.Engine("gaussian")
result = eng.run(prog)

state = result.state

# Wigner function value at a point in phase space
W = state.wigner(0, np.arange(-3, 3, 0.1), np.arange(-3, 3, 0.1))
print(f"Wigner function computed over {W.shape} grid points")

# Mean photon number
n_mean = state.mean_photon(0)
print(f"Mean photon number in mode 0: {n_mean[0]:.3f}")

# Covariance matrix (describes Gaussian state fully)
cov = state.cov()
print(f"Covariance matrix shape: {cov.shape}")

The Wigner function is a phase-space representation of a quantum state. It is positive everywhere for classical-like states, yet it becomes negative in regions corresponding to non-classical states (such as Schrödinger cat states).

Xanadu’s Borealis photonic processor, the machine behind the 2022 advantage result, is no longer publicly accessible: Xanadu retired it from Amazon Braket in June 2023, and it is not offered through the Xanadu Cloud. In recent years the only Xanadu hardware available online has been the much smaller X8 chip, so check the Xanadu Cloud documentation for current device availability before planning a hardware run. The remote execution pattern looks like this:

import strawberryfields as sf

# Connect to Xanadu Cloud (requires account + API key)
# sf.store_account("YOUR_API_KEY")

# Run on remote photonic hardware (device availability changes;
# check Xanadu Cloud for the current device list)
# eng = sf.RemoteEngine("X8")

# Your program here - limited to circuits the device supports
# result = eng.run(prog, shots=100)

Borealis utilized time-multiplexed photonic loops containing 216 squeezed modes. Xanadu demonstrated in 2022 that Borealis could draw a sample in tens of microseconds, a performance vastly superior to the estimated 9,000 years required for the same problem using classical supercomputers.

Photonic quantum computing, exemplified by systems like Strawberry Fields, differs significantly from traditional qubit approaches such as Qiskit or Cirq:

Property	Photonic (Strawberry Fields)	Qubit-based (Qiskit, Cirq)
State space	Continuous (quadratures)	Discrete (0/1)
Measurement output	Continuous values or photon counts	Binary 0 or 1
Operating temperature	Room temperature for the circuit itself (detectors typically still need cryogenic cooling)	Millikelvin cooling (superconducting qubits)
Natural applications	Gaussian boson sampling, optimization, machine learning	General-purpose algorithms such as Shor’s or Grover’s
Entanglement mechanism	Two-mode squeezing	Gates such as CNOT
Dominant noise source	Photon loss	Decoherence and gate errors
Key performance metric	Squeezing strength (dB)	Gate fidelity

This is a rough guide rather than a strict rulebook. In practice, the choice of platform depends heavily on which specific problem you are trying to solve and what hardware you have access to.

For further exploration, users can consult the Strawberry Fields documentation. To explore differentiable quantum programming and quantum machine learning, PennyLane, also from Xanadu, is available. The GBS applications library provides tools for graph optimization, molecular vibrational spectra, and point process sampling. Finally, the pip install thewalrus command installs Xanadu’s library for handling hafnians and Gaussian boson sampling mathematics.
